Appli Parts APAC-330120 Heavy Duty Contactor 3 Poles 30A 120V Coil Replacement for AC Compressors and Electrical Applications UL Certified E476929

Appli Parts APAC-330120 Heavy Duty Contactor 3 Poles 30A 120V Coil Replacement for AC Compressors and Electrical Applications UL Certified E476929

Reviews (0) Add a review

$46.01
Price per Each

Appli Parts APAC-330120 Heavy Duty Contactor 3 Poles 30A 120V Coil Replacement for AC Compressors and Electrical Applications UL Certified E476929
Application: Heavy-duty 3 Poles 30A 120V coil contactor for air conditioners, heat pumps, water pumps, refrigeration systems, and electric motors. Universal replacement for HVAC and industrial applications.
Ratings: 3 Poles 30A full load (FLA). Locked rotor (LRA): 240/277V 180A, 480V 150A, 600V 100A, UL Certified E476929 for reliable operation and long service life.
Coil Data: Resistance 180 Ohm (DC measurement, coil 120V). Switching capacity: 40A (resistive load: FLA 30A, LRA: 240/277V at 180A, 480V at 150A, 600V at 100A). Nominal Inrush 65VA at 50Hz / 60VA at 60Hz, Nominal Sealed 7.5VA at 50Hz / 6VA at 60 Hz.
Electrical Performance: Maximum Pick-Up 88V, Minimum Drop-Out 20/70V, Maximum Voltage 132V. Insulation Resistance: Class B, 130C, for enhanced safety and reliability.
Certified Quality & Replaces: High-quality materials, UL tested for durability and consistent performance. Replaces: C330B / 17336 / 42BF35AFBBT / C25DND330A / CR353AC3AA1AB / GDP3031 / HCCY3XT02AT303 Confirm cross-reference and specifications before replacement.

Weight : 1.2 LBR
Volume : 0.01880787 FTQ
Model : APAC-330120
UPC-EAN : 814245022020

Heavy duty HVAC contactor replacement for ac compressors and other electrical applications UL 476929

This product replaces several part numbers, models and brands not limited to:

5KAK0, 42BE35AFBBT, 42BF35AF, 42BF35AFBBT, 49C082, 8910DPA33V02, 17332, 17336, 61430, 61431, 61751, 912303001, C3M30B, C25DND330A, C25DNF330A, C25ENF440A, C330B, CON-3/120/30, CR353AC3AA1AB, CR453AC3AAA, DP3030B1001, DP3030B5002, DP3030B5003, DP330120F, DP-EP30A120, DPA33V02, DPE303120, EC303120, F30A3P120V, GDP3031, HCCY3XT02AT303, P282-0322, SE3705M, TMX330B2, XMC0-323FBBC

SKU G0323.3031

Condition New

Data sheet

Product Feature: Application: Heavy-duty 3 Poles 30A 120V coil contactor for air conditioners, heat pumps, water pumps, refrigeration systems, and electric motors. Universal replacement for HVAC and industrial applications.
Certified Quality & Replaces: High-quality materials, UL tested for durability and consistent performance. Replaces: C330B / 17336 / 42BF35AFBBT / C25DND330A / CR353AC3AA1AB / GDP3031 / HCCY3XT02AT303 Confirm cross-reference and specifications before repl
Coil Data: Resistance 180 Ohm (DC measurement, coil 120V). Switching capacity: 40A (resistive load: FLA 30A, LRA: 240/277V at 180A, 480V at 150A, 600V at 100A). Nominal Inrush 65VA at 50Hz / 60VA at 60Hz, Nominal Sealed 7.5VA at 50Hz / 6VA at 60 Hz.
Electrical Performance: Maximum Pick-Up 88V, Minimum Drop-Out 20/70V, Maximum Voltage 132V. Insulation Resistance: Class B, 130C, for enhanced safety and reliability.
Ratings: 3 Poles 30A full load (FLA). Locked rotor (LRA): 240/277V 180A, 480V 150A, 600V 100A, UL Certified E476929 for reliable operation and long service life.
Weight: 1.2 LBR
Volume: 0.01880787 FTQ
Model: APAC-330120
UPC-EAN: 814245022020
